R88M-G05030H-Z OMRON Between power supply power terminals and FG terminal 1500 VAC

Name: R88M-G05030H-Z OMRON Between power supply power terminals and FG terminal 1500 VAC
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: R88M-G05030H-Z
Price: 210.00 USD
Availability: InStock

Nazwa marki:	OMRON
Numer modelu:	R88M-G05030H-Z
MOQ:	1
Cena £:	Negocjowalne
Warunki płatności:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Zdolność do zaopatrzenia:	In Stock

Szczegółowe informacje

Opis produktu

Szczegółowe informacje

Place of Origin:

Japan

Orzecznictwo:

Packaging Details:

New Original Box

Supply Ability:

In Stock

Opis produktu

Detailed Product Description

Brand:

OMRON

Model:

R88M-G05030H-Z

Origion:

Japan

Lead Time:

5-8 Work Days

Highlight:

ethernet plc controllers

industrial automation using plc

OMRON R88M-G05030H-Z Between power supply/power terminals and FG terminal: 1,500 VAC

Built-in safety: multi-drives in a single safety relay circuit

The two safety inputs and the external device monitoring (EDM) output can be linked from one servo drive to another without using additional safety relays. Up to 8 servo drives can be connected to a single safety relay, saving hardware and wiring costs.

Full closed loop

The G5 Series has a built-in external encoder input for full closed loop operation, for when additional accuracy is required. The external encoder input eliminates the errors caused by, for example, slip in the material.

Double registration input

The G5 Series increases application versatility by providing 2 independent registration inputs per axis, especially relevant for applications such as flow wrappers. By registering the product input position and the mark position on the film, the system can make relative corrections ensuring high accuracy with a simple mechanical design.

Accurate motion control in a compact size servo drive family. EtherCAT and safety built-in.

• EtherCAT, ML-II and Analog/Pulse servo drive models
• Safety conforming ISO13849-1 Performance Level D
• High-response frequency of 2 kHz
• High accuracy provided by 20 bits encoder
• Full closed loop encoder built-in
• Real time auto-tuning
• Advanced tuning algorithms (Anti-vibration function, torque feedforward, disturbance observer)
• IP67 protection in all motor models
• Drive Programming: embedded indexer functionality in the Analog/Pulse models

Ratings

• 120 VAC Single-phase 50 W to 400 W
• 230 VAC Single-phase 50 W to 1.5 kW
• 230 VAC Three-phase 2 kW to 5 kW
• 460 VAC Three-phase 600 W to 15 kW

AC Servo Drives

General Specifications

Item		Specifications
Ambient operating temperature and humidity		0 to 55 °C, 20% to 85% max. (with no condensation)
Storage ambient temperature and humidity		-20 to 65°C, 20% to 85% max. (with no condensation)
Operating and storage atmosphere		No corrosive gases
Vibration resistance		10 to 60 Hz and at an acceleration of 5.88 m/s² or less (Not to be run continuously at the resonance point)
Insulation resistance		Between power supply terminals/power terminals and FG terminal: 0.5 MΩ min. (at 500 VDC)
Dielectric strength		Between power supply/power terminals and FG terminal: 1,500 VAC for 1 min at 50/60 Hz
Protective structure		Built into panel
EC Directives *	EMC Directive	EN 55011, EN 61000-6-2, EN 61800-3
	Low Voltage Directive	EN 61800-5-1
	Machinery　Directives	EN954-1 (Cat.3), EN ISO13849-1 (Cat.3) (PLc, d), ISO13849-1 (Cat.3) (PLc, d), EN61508 (SIL2), EN62061 (SIL2), EN61800-5-2 (STO), IEC61326-3-1 (SIL 2)
UL standards		UL 508C
CSA standards		CSA C22.2 No.14
Korean Radio Regulations (KC)		Certified

* The certification from third party is issued in combination with the revolution type motor. The conformance as the whole
system should be checked by machine builder.
Note: 1. The above items reflect individual evaluation testing. The results may differ under compound conditions.
Note: 2. Always disconnect all connections to the Servo Drive before you perform insulation resistance tests on it. If you
perform an insulation resistance test while the Servo Drive is connected, the Servo Drive may be damaged.
Never perform dielectric strength tests on the Servo Drive. Failure to follow this precaution may result in
damaging internal elements.
Note: 3. Some Servo Drive parts will require maintenance. For details, refer to the G5 series USER'S MANUAL.
Confirm the Manual No. that is listed in Related Manuals.
Note: 4. Vibration, unstable movement, or accoustic noise may occur by an exogenous noise. In such case, please
reduce incoming noise as referred in G5 series user's manuals.
