PLC Programmable Logic Controller TXP-M2CGNPM0000N TOPWORX Emerson Available with SOV and HART options

PLC Programmable Logic Controller TXP-M2CGNPM0000N TOPWORX Emerson Available with SOV and HART options

the stainless steel, 35-Series GO™ Switch Hermetically-Sealed, Stainless Steel, DPDT Proximity Switch

For over fifty years, GO™ Switch, all in one proximity sensor and limit switches, have set the standard for reliability and durability in the process industries. Their unique operating principle and best-in-class capabilities have made them the most specified switch in the world for demanding process applications.

TopWorx™ has once again improved on greatness.

The 35-Series GO™ Switch is available in two versions: The original Single Pole Double Throw GO™ Switch or the stainless steel, Double Pole Double Throw, version.

Features:

- One-piece, stainless steel housing

- Hermetically-sealed, Double Pole Double Throw contacts

- Suitable for both Ex d and Intrinsically Safe applications

- Up to four (4) switches in a single enclosure

- Extremely low hysteresis

- PLC and higher current ratings with AC/DC

- NO/NC wiring flexibility

- 4amp/120vac and 3amp/24vdc

- Available with SOV and HART options

4-20mA POSITION TRANSMITTER

- Fully potted electronic module with LEDs and Auto Calibration feature

- Precise setting of the zero and span can be done in seconds for both CW and CCW rotation with a simple push button

- Position feedback sensor is mounted directly to the switchbox shaft eliminating backlash caused by traditional gear train

- Up to 300° rotation for choke valve applications

- The need for re-calibration is eliminated

- Available with GO Switches

TopWorx™ Visual Indicators

A variety of indicators to fit every application, including multiple color combinations such as Green/Red and Yellow/Black, plus three-way, 90° and 180° flow paths. Other languages are also available upon request.

Cold Temp to -60°C/-76°F

The TopWorx™ D-Series will give accurate position indication down to -60°C with the use of the GO Switch.

TopWorx TVF Now Available with LED’s

The TVF with high intensity LEDs will give you a clear and bright visual indication of your valve state in the darkest of conditions. Have the confidence you need to ensure your valve is in the proper state visually and electrically with TopWorx.

Benefits:

- Intrinsically Safe or Zone 2/Div 2 approved

- Available with GO Switches, reeds, or mechanical

- 10 point terminal strip

- Fully integrated options with internal pneumatics

- Conformal coated PCB board for enhanced reliability

- 24VDC or 120VAC @ 250mA

- Type 4X, IP67 Rated
